| Paper Gaskets Materials/ Non-asbestos materials |
| Material Model |
BA-08 |
| Material Overview |
BA-08 is produced using papermaking technology, with high density and good material uniformity. It has excellent properties such as oil resistance, compression rate, rebound rate, and transverse tensile strength (>18Mpa). |
| Basis |
Aramid fibers, inorganic fillers |
| Binder |
NBR-Nitrile Butadiene Rubber |
| Applicable Medium |
Fuel, lubricating oil, transmission oil, engine oil, air, water, low acidity, low alkalinity, etc |
| Application Field |
Gearboxes, Diesel Engines, Air Compressors, Gasoline Engines, Motorcycles, Construction Machinery, General Machinery, Etc. |
| Application Temperature |
Continuous，250℃；Max. Peak，300℃ |
| Trademark customization |
Customers can print their own trademark logos to meet their customized needs. |
Specification Properties
|
|
Property
|
Unit
|
Value
|
Test Method
|
|
Density
|
g/cm3
|
≥ 1.40
|
ASTM F1315
|
|
Tensile Strength, AMD
|
MPa
|
≥ 18.0
|
ASTM F152
|
|
Compressibility（34.5 MPa）
|
%
|
5~15
|
ASTM F36
|
|
Recovery
Creep Relaxation
|
%
%
|
≥ 50
< 25
|
ASTM F36
ASTM F-38
|
|
Immersion Test #903 Oil (150℃×5h)
|
ASTM F146
|
|
Tensile after immersion
|
MPa
|
≥ 15.0
|
|
Weight Change
|
%
|
≤ 20
|
|
Thickness Change
|
%
|
≤ 10
|
|
Immersion Test, Fuel B（21-30 ℃ ×5h）
|
ASTM F146
|
|
Weight Change
|
%
|
≤ 20
|
|
Thickness Change
|
%
|
≤ 10
|
|
